Descripción
de este producto
| Interface |
TTL,RS-232,USB (Virtual COM) |
| Card type |
ISO/IEC 7810 ID-1, ISO/IEC 7811-1,2,6 |
| Card feeding speed |
Card feeding speed |
| Service life of Mag. Head |
500,000 passes |
| Power |
DC+5V |
| Operating temperature & Humidity |
-20 ~ 60ºC
20 ~ 80%RH (non condensing) |
| Storage temperature & Humidity |
-20 ~ 70ºC
20 ~ 80%RH (non condensing) |
| Weight |
Approx.40g (MCR-770N) |
|
Model Number |
TRK1 |
TRK2 |
TRK3 |
I/F |
Size |
|
MCR-760N-1R-0101 |
R |
|
|
TTL |
22(W)x90(L)x24(H)mm |
|
MCR-770N-1R-0101 |
|
R |
|
TTL |
22(W)x90(L)x24(H)mm |
|
MCR-780N-1R-0101 |
|
|
R |
TTL |
22(W)x90(L)x24(H)mm |
|
MCR-730N-2R-0101 |
R |
R |
|
TTL |
22(W)x90(L)x24(H)mm |
|
MCR-710N-2R-0101 |
|
R |
R |
TTL |
22(W)x90(L)x24(H)mm |
|
MCR-790N-3R-0101 |
R |
R |
R |
TTL |
22(W)x90(L)x24(H)mm |
|
SCR-767S-1R-0101 |
R |
|
|
RS-232 |
22(W)x90(L)x24(H)mm |
|
SCR-777S-1R-0101 |
|
R |
|
RS-232 |
22(W)x90(L)x24(H)mm |
|
SCR-787S-1R-0101 |
|
|
R |
RS-232 |
22(W)x90(L)x24(H)mm |
|
SCR-737S-2R-0101 |
R |
R |
|
RS-232 |
22(W)x90(L)x24(H)mm |
|
SCR-717S-2R-0101 |
|
R |
R |
RS-232 |
22(W)x90(L)x24(H)mm |
|
SCR-797S-3R-0101 |
R |
R |
R |
RS-232 |
22(W)x90(L)x24(H)mm |
|
SCR-767U-1R-0101 |
R |
|
|
USB |
22(W)x90(L)x24(H)mm |
|
SCR-777U-1R-0101 |
|
R |
|
USB |
22(W)x90(L)x24(H)mm |
|
SCR-787U-1R-0101 |
|
|
R |
USB |
22(W)x90(L)x24(H)mm |
|
SCR-737U-2R-0101 |
R |
R |
|
USB |
22(W)x90(L)x24(H)mm |
|
SCR-717U-2R-0101 |
|
R |
R |
USB |
22(W)x90(L)x24(H)mm |
|
SCR-797U-3R-0101 |
R |
R |
R |
USB |
22(W)x90(L)x24(H)mm
; |
|
